Description

Longer Cycle Life : Offers up to 20 times longer cycle life and five times longer float/calendar life than lead acid battery ,

helping to minimize replacement cost and reduce total cost of ownership

Lighter Weight : About 40% of the weight of a comparable lead acid battery . A " drop in" replacement for lead acid batteries

Higher Power : Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity

Wider Temperature Range : -20℃~60℃

Superior Safety: Lithium Iron Phosphate chemistry eleminates the risk of explosion or combustion due to high impact overcharging or short circuit situation

Features

 High energy density, small footprint, short construction period, strong environmental adaptability

Standardized components, modular architecture, easy for expansion

 Battery module within the layered stack design, with more than 10 years of long design life

Efficient battery module and system cooling design

 The use of international advanced IGBT and intelligent power module, with high power fast adjustment capability

BMS battery management system with SOC automatic calibration and high current active balance function, combined with the perfect operation control and management strategies to achieve accurate and efficient management


Specifications

Voltage
V
Capacity
AH
Energy
KWh
Item Life Cycles
DOD70%
Warranty
Months
Max Output
W
Size:mm
L-W-H
Approximately
Weight kg
 Case Remark Picture1
  50 0.64 Battery 3500 60 730W 197-165-169 5.2 Plastic Just single battery
in Use,
NO to be in series or parallel

  Charger   18 14.6V
10A

12.8
(12V)
100 1.28 Battery 3500 60 1500W 330-173-216 11.5 Plastic

Charger   18 300W
200 2.56 Battery 3500 60 2000W 520-238-218 21.5 Plastic

Charger   18 400W
300 3.84 Battery 3500 60 2000W 520-238-218 31.5 Plastic

Charger   18 500W
25.6
(24V)
100 2.56 Battery 3500 60 2000W 520-267-228 21.5 Plastic Just single battery
in Use,
NO to be in series or parallel


Charger   18 600W
200 5.12 Battery 3500 60 3000W 520-267-228 43.0 Plastic





Charger   18 800W
300 7.68 Battery 3500 60 3000W TBD 75.0 Steel
Charger   18 900W
51.2
(48V)
100 5.12 Battery 3500 60 5000W 520-267-228 43.0 Plastic Just single battery
in Use,
NO to be in series or parallel


Charger   18 1000W
200 10.24 Battery 3500 60 5000W 871x362x394 89.0 Steel

Charger   18 1500W
300 15.36 Battery 3500 60 5000W TBD 130.0 Steel

Charger   18 2000W
